Thermal Insulation Enclosures TermoTisa


The thermal insulation Termotisa is ideal when it is necessary thermal insulate in the electrical cabinet because of the outside temperature, sun, both cold and heat insulation in outdoor enviroments.

Thermal Insulation Enclosures TermoTisa · Delvalle Box
Thermal Insulation Enclosures TermoTisa · Delvalle Box


Thermal Insulation enclosures TermoTisa In Delvalle, we know the concerns of our customers to avoid overheating of the cabinets because external agents such as the sun, heat sources and locations with extreme heat.
Delvalle's engineering team have designed TermoTisa, based Polyurethane 15mm porous support coated with a braided polyester layer to put on the walls of the cabinets and ensures insulation 0.018 W (mK).
Perfect insulation between the outside and inside the cabinet.

The material is resistant to liquids, the compound does not come off , and it is self extiguible electric current insulator.
The insulating TermoTisa designed by Delvalle for more than two years of research, behaves perfect for thermal and electrical insulation in the application of electrical cabinets.


Discover the advantages

Thermal Absorption coefficient of thermal conductivity : 0.018 W / (mK ) .
Resistant to liquids.
The material is stable under certain conditions ( noise, vibration , temperature).
Insulation material to electrical current.
Self-extinguishing material .
The material is biologically inert, non-hazardous and non-degradable.
Color Black.
High quality material : not peel off and not generate bags .
Resistance break > L = 250 , t = 150 as standard D41 1029.
Rupture Elongation L = 70 , T = 150 + 15 1029 according to Standard D41 .
Net Density 22 kg/m3.
Tensile strength 220 kPa according to Iso 1798.
Number of pores per cm2 = 14, according to BS 4443.


Can be placed on our entire series of cabinets and particularly in outdoor or outdoor .
 Applications outside or outdoors.
 Fitted near heat sources.
 When we want to save energy by insulating the outside temperature to inside the cabinet .
 For electrical insulation of the inner walls of cabinet
