We design and manufacture electrical cabinets for areas with extreme temperature conditions, both in high temperature +250ºC and in low temperature -60ºC; ours cabinets are prepared for a high humidity concentration or a very dry environment, with the guarantee that the electrical components will continue operating after many years.
| Minimum Measurements | A=1185-2060mm B=600-800mm P=800-600mm |
|---|---|
| Maximum Double Door Measurements | A=1835mm B=1350mm P=800mm |
| Minimum Plate Measurements | A=965-1840mm |
| Minimum Plate Measurements | B=530-730mm |
| Body Thickness | 1.5 mm | 15/10 mm 0.059 " | 16 Gauge |
| Door Type | Blind door |
| Opening Type | Swivel with concealed hinges |
| Closing System | Rotary handle |
| Material | AISI 304L/AISI 316L |
| Finish | Satin finish |
| Sealing Gasket | Polyurethane |
| Working Temperature | -40°C a +100°C (reducida exposición +160ºC) |
| Maximum Voltage | 1000 V |
| Alternative Materials | AISI 316L, Galvanized, Aluminum |
|---|---|
| Alternative Finishes | Painted RAL 7035 |
| Alternative Closing Systems | Rotary handle |
| Alternative Door | Blind door |
| Alternative Gaskets | silicone (-60°C to +180°C) |
| Machinable Area | Puerta: 905x430-1780x630, Lateral: 925x715-1800x515 |
|
REFERENCES 1 DOOR |
DIMENSIONS AND DATA |
||||||||
|
STAINLESS STEEL |
ALUMINUM |
GALVANIZED |
RACK UNITS (U) |
HEIGHT -A- |
WIDTH -B- |
DEPTH -C- |
MACHINABLE AREA |
PLATE DIMENSIONS |
|
|
DOOR |
SIDE |
||||||||
|
TRI126060 |
TRAL126060 |
TRG126060 |
20 U |
1185 |
600 |
600 |
905×430 |
925×515 |
965×530 |
|
TRI126080 |
TRAL126080 |
TRG126080 |
20 U |
1185 |
600 |
800 |
905×430 |
925×715 |
965×530 |
|
TRI128060 |
TRAL128060 |
TRG128060 |
20 U |
1185 |
800 |
600 |
905×630 |
925×515 |
965×730 |
|
TRI128080 |
TRAL128080 |
TRG128080 |
20 U |
1185 |
800 |
800 |
905×630 |
925×715 |
965×730 |
|
TRI146060 |
TRAL146060 |
TRG146060 |
25 U |
1385 |
600 |
600 |
1105×430 |
1125×515 |
1165×530 |
|
TRI146080 |
TRAL146080 |
TRG146080 |
25 U |
1385 |
600 |
800 |
1105×430 |
1125×715 |
1165×530 |
|
TRI148060 |
TRAL148060 |
TRG148060 |
25 U |
1385 |
800 |
600 |
1105×630 |
1125×515 |
1165×730 |
|
TRI148080 |
TRAL148080 |
TRG148080 |
25 U |
1385 |
800 |
800 |
1105×630 |
1125×715 |
1165×730 |
|
TRI166060 |
TRAL166060 |
TRG166060 |
30 U |
1585 |
600 |
600 |
1305×430 |
1325×515 |
1365×530 |
|
TRI166080 |
TRAL166080 |
TRG166080 |
30 U |
1585 |
600 |
800 |
1305×430 |
1325×715 |
1365×530 |
|
TRI168060 |
TRAL168060 |
TRG168060 |
30 U |
1585 |
800 |
600 |
1305×630 |
1325×515 |
1365×730 |
|
TRI168080 |
TRAL168080 |
TRG168080 |
30 U |
1585 |
800 |
800 |
1305×630 |
1325×715 |
1365×730 |
|
TRI186060 |
TRAL186060 |
TRG186060 |
35 U |
1885 |
600 |
600 |
1555×430 |
1575×515 |
1615×530 |
|
TRI186080 |
TRAL186080 |
TRG186080 |
35 U |
1885 |
600 |
800 |
1555×430 |
1575×715 |
1615×530 |
|
TRI188060 |
TRAL188060 |
TRG188060 |
35 U |
1885 |
800 |
600 |
1555×630 |
1575×515 |
1615×730 |
|
TRI188080 |
TRAL188080 |
TRG188080 |
35 U |
1885 |
800 |
800 |
1555×630 |
1575×715 |
1615×730 |
|
TRI206060 |
TRAL206060 |
TRG206060 |
40 U |
2060 |
600 |
600 |
1780×430 |
1800×515 |
1840×530 |
|
TRI206080 |
TRAL206080 |
TRG206080 |
40 U |
2060 |
600 |
800 |
1780×430 |
1800×715 |
1840×530 |
|
TRI208060 |
TRAL208060 |
TRG208060 |
40 U |
2060 |
800 |
600 |
1780×630 |
1800×515 |
1840×730 |
|
TRI208080 |
TRAL208080 |
TRG208080 |
40 U |
2060 |
800 |
800 |
1780×630 |
1800×715 |
1840×730 |
|
REFERENCES 2 DOORS |
DIMENSIONS (mm) |
|||||
|
STAINLESS STEEL |
ALUMINUM |
GALVANIZED |
RACK UNITS (U) |
HEIGHT -A- |
WIDTH -B- |
DEPTH -C- |
|
TRI121360D |
TRAL121360D |
TRG121360D |
20 U |
1160 |
1350 |
600 |
|
TRI121380D |
TRAL121380D |
TRG121380D |
20 U |
1160 |
1350 |
800 |
|
TRI141360D |
TRAL141360D |
TRG141360D |
25 U |
1385 |
1350 |
600 |
|
TRI141380D |
TRAL141380D |
TRG141380D |
25 U |
1385 |
1350 |
800 |
|
TRI161360D |
TRAL161360D |
TRG161360D |
30 U |
1610 |
1350 |
600 |
|
TRI161380D |
TRAL161380D |
TRG161380D |
30 U |
1610 |
1350 |
800 |
|
TRI181360D |
TRAL181360D |
TRG181360D |
35 U |
1835 |
1350 |
600 |
|
TRI181380D |
TRAL181380D |
TRG181380D |
35 U |
1835 |
1350 |
800 |
